Customize OEM 7.0 Inch 50 Pin 800480 400cd TFT LCD Screen Display Module

Customize OEM 7.0 Inch 50 Pin 800480 400cd TFT LCD Screen Display Module

  • High Light

    800x480 TFT LCD Screen Module

    ,

    400cd/m2 TFT LCD Screen Module

    ,

    800x480 7 inch tft lcd arduino

  • Display Size
    7.0" TFT LCD Display Module
  • Display Mode
    Normally White, Transmissive LCD
  • Outside Dimensions
    165(H)x 100(V)x5.7(D)mm
  • Active Area
    154.08 (H) X 85.92 (V)
  • Number Of Pixels
    800 RGB (H) X 480 (V)
  • Pixel Pitch
    0.1926mm (H) X 0.1790 Mm (V)s
  • Pixel Arrangement
    RGB Vertical Stripes
  • Backlight
    White LED
  • Name
    OEM 7.0 Inch 50 Pin 800480 400cd TFT LCD Screen Display Module
  • Warranty
    12months
  • Place of Origin
    Shenzhen, China
  • Brand Name
    Qihang
  • Certification
    ROHS/CE
  • Model Number
    JXL-7.0TFT-W1
  • Minimum Order Quantity
    1 pcs
  • Price
    Negotiable
  • Packaging Details
    Tray , Standard carton
  • Delivery Time
    10-15 Days
  • Payment Terms
    T/T, L/C, D/A, D/P, Western Union, MoneyGram, paypal
  • Supply Ability
    300000 Per Month

Customize OEM 7.0 Inch 50 Pin 800480 400cd TFT LCD Screen Display Module

OEM 7.0 Inch 50 Pin 800480 400cd TFT LCD Screen Display Module

Introduction

Customize OEM 7.0 Inch 50 Pin 800480 400cd TFT LCD Screen Display Module 0
Customize OEM 7.0 Inch 50 Pin 800480 400cd TFT LCD Screen Display Module 1
CPT Display model 7DD FOG is a color active matrix thin film transistor (TFT) liquid crystal display (LCD) that
uses amorphous silicon TFT as a switching device. This model is composed of a TFT LCD panel and a driving
circuit.This TFT LCD has a 7.0 (16:9) inch diagonally measured active display area with (800 horizontal by480
vertical pixe l) resolution.

Features

7 (16:9 diagonal) inch configuration
Compatible with NTSC & PAL system
Image Reversion: UP/DOWN and LEFT/RIGHT

ROHS design

Quick Details

Name OEM 7.0 Inch 50 Pin 800480 400cd TFT LCD Screen Display Module
Display Size 7.0" TFT
Display Mode White, Transmissive / Positive LCD
Viewing Direction 6 O’CLOCK
Volte 3.3 -5.0 V
Backlight 15 Chip-White LED Light
Operating Temp: -20 ℃ - 70 ℃
Storage Temp: -30 ℃ - 80 ℃
Input Signals R.G.B. Vertical Stripe
Number of Pin 50 Pins

Sample Policy

Contact us for information regarding our sample policy

Note

*1) Liquid Crystal driving voltage.
Due to the characteristics of LC Material, this voltage vary with environmental temperature.
*2) Temp.>60℃, Absolute humidity shall be less than 90%RH at 60℃
*3) Temp.≤60℃, 90%RH MAX.

Shipping Warranty

Customize OEM 7.0 Inch 50 Pin 800480 400cd TFT LCD Screen Display Module 2Customize OEM 7.0 Inch 50 Pin 800480 400cd TFT LCD Screen Display Module 3

We usually ship goods By DHL, UPS, EMS, Singpost airmail, and HongKong Airmail.
DHL: 3-5 days
UPS: 5-7 days
EMS: 10-15 working days
Chinapost/HongKong Airmail: 7- 25 working days. At most 45 days.
If you have not received the goods during the normal time, please contact us for checking the package status timely online or by email.

Product Application

We provide a verity of LCD display screen module according to customers' various requests, TFT LCD Screen Module, Graphic LCD Display Module, Character LCD Display Module, Segment LCD Module, OLED Display Module, LCD Display Led Backlight, LCD Display Led Backlight, Touch Panel, Smart Screen Module.

1.We provide a verity of lcd panel and lcd module, Including TN LCD, HTN, STN, FSTN, VA LCD, including COB and COG IC connection.

2.Character Module series for 16x1, 16x2, 16x4, 20x1, 20x2 characters

3.Graphic Module series for 96x16 dots,122x32 dots,128x32 dots, 128x64 dots, 160x32dots, 160x128 dots, 160x160 dots, 192x32 dots, 192x64 dots, 160x132 dots, 240x128 dots, 320x240 dots series.

Customize OEM 7.0 Inch 50 Pin 800480 400cd TFT LCD Screen Display Module 4

Product replacement and warranty

If you have any prodcut quality problem, you can send it back to us with the original condition,we will repair or exchange new one for you.
If you have any using problem of the products which buy from Qihang, please feedback to us first, and we will discuss the issue with you. Via our technical support, we can dig out your using problem via our technical support in most of cases.
Lost Products: If products get lost in delivery, or you still do not get your item for a long time, please contact our customer service timely. We will deal with this ASAP. Please do not deal with it all by yourself, we want you communicate with us. Usually, we will provide tracking number and tracking link timely. If products get lost on the way and we get confirm from couriers, we will arrange redelivery for your products. If you want ship it through express, then you need to pay express shipping fee.

Product Drawing

Customize OEM 7.0 Inch 50 Pin 800480 400cd TFT LCD Screen Display Module 5
