5.0V Zebra Connector Reflective STN HTN FSTN 7 Segment LCD Display Panel

5.0V Zebra Connector Reflective STN HTN FSTN 7 Segment LCD Display Panel

  • High Light

    5.0V Reflective LCD Panel


    Zebra Connector Reflective LCD Panel


    Glass STN Reflective LCD Display

  • Type
    Zebra Connector Reflective STN HTN FSTN 7 Segment LCD Display Panel
  • LCD Operating Voltage
  • Material
    STN (Y-G)
  • Connector
  • Operating Temp
  • Storage Temp
  • Custom
  • Viewing Direction
    6:00 Hour
  • Deminsion
    62.0×44.0 Mm
  • A.A.
    56.27x38.35 Mm
  • Place of Origin
    Shenzhen, China
  • Brand Name
  • Certification
  • Model Number
  • Minimum Order Quantity
    1 pcs
  • Price
  • Packaging Details
    Tray , Standard carton
  • Delivery Time
    10-15 Days
  • Payment Terms
    T/T, L/C, D/A, D/P, Western Union, MoneyGram, paypal
  • Supply Ability
    300000 Per Month

5.0V Zebra Connector Reflective STN HTN FSTN 7 Segment LCD Display Panel

Zebra Connector Reflective STN HTN FSTN 7 Segment LCD Display Panel


Product Details


Name Connector Reflective STN HTN FSTN 7 Segment LCD Display Panel
Place of Origin Shenzhen, Guangdong province, CN
Operating Voltage 5.0V
Viewing Angle 6:00 O'clock
LCD Mode STN Yellow-green film
Display Mode Refective
Voltage Driving Dynamic or static
Connector Zebra
Operating Temperature -20℃~+70℃
Storage Temperature -30℃~+80℃
OEM/ODM Accecpted
System Design Lcd module related system software and hardware design accepted
Warranty 12 moths free, payed warranty lifttime
LCD Module Type Meter Module
Sample Lead Time 3-7 working days
Customize Lead Time 15-30 working days
Packaging One module in a foam board, all in small carton foam protecting, small carton in big carton
Cetification ISO, SGS


What can we custom?


Display type: TN / HTN / STN / FSTN / FFSTN / DFSTN / VA

LCD structure: LCD Panel With / Without backlight

Banding type: COB / COG / COF

Polarizer: Transflective, Transmissive, Reflective, Anti- Glare, Anti-UV

Background: Gray Film, Yellow-Green Film, Blue Film, Black Film

Operating temperature: -30 ℃ ~+85 ℃, Customization

Connector / Connection: Metal PIN, Zebra, Heat seal, Flat cable (FPC)


How to process a custom segment LCD panel

  1. Discuss LCD details
  2. Quote price according to customer's LCD idea or design
  3. Pay for the mould fee
  4. Prepare drawings for customer to comfirm within 3 days
  5. Make samples based on confirmed drawing with 20 days
  6. Process with mass order according to customers production schedule, delivery time within 30 - 50 day




Shenzhen Qihang Electronic technology Co.,Ltd. have almost 10 Years of LCD module / LCM Production Experience,We can design, develop and produce customized LCD, LCM.
We currently produce LCD of TN, HTN, STN, FSTN, VA,lcd Module and Touch screen. Shenzhen Qihang Electronic technology Co.,Ltd. (established in 2012, the main investment direction is small and medium-sized LCD display LCD and its extension related products. Development so far, Qihang has a LCD factory and a LCM plant in China).

Since LCD Glass / LCD panel only displays fixed images, the industry is basically a fixed product, and each customer uses different 7 segment lcd panel. If your time is not urgent, our company suggests you directly mold making and customization:

1. Compared with other industries, such as machinery manufacturing industry, the mold fee of segment code screen is extremely low, basically USD 90 ~ USD 150, and the mold cost will be refunded later.

2. Customization can better tailor products to your satisfaction


3. 7 segment Lcd screen customization screen for the whole industry, basicially not standard, it is difficult to find a and you your required size and display the same image products, even if can find, also need to spend a lot of time, and even if you're lucky enough to find, to find is someone else's products, is likely to be your competitors are using Lcd screen, it is easy to cause infringement and other unnecessary trouble.


Therefore, our company suggests that you open mold customization!


If you want to buy some stock to try, we have many male models for you. You can consult us by email and we will get back to you as soon as possible.

Hope our company can become your good partner!


Packaging and delivery

Packing Details : Packing with box, it also can package as your request
Delivery Details : 3-30 days delivery via DHL, UPS, TNT, FEDEX, HK Register




Q: Can you provide product drawings and test reports?
A: According to customer needs, our company can provide product related information and test reports.

Q: Are you open to OEM processing?
A: Yes, we can OEM.

Q:How to control the quality of products?
A: The company has a professional quality team, and all products are shipped with 100% inspection.

Q:The LCD screen can be exported directly? what certification could provide ?
A:Liquid crystal products comply with the RoHS standard, can be directly exported.Products by RoHS, CE, SGS certification.

Q: What kind of packaging? The transport process will not be damaged?
A:Our products are divided into three categories, small size screens use foam packaging, small and medium size use knife card isolation packaging, large size screens are used in aircraft box packaging, all packages are protected by outer box and strapping to ensure the safety of material transportation.


Q:Can we customize products? How many charges?
A:The LCD screen can be customized, customized products have the minimum purchase quantity constraint.Mold fee for all kinds of products are not the same, the general principle is: LCD mold fee category: TN was low,STN was high.

Q: How long is the warranty and service of the product?
A: The damage caused by the product during normal use, during the warranty period, our company is free to repair, the warranty period, or the damage caused by improper use is not within the scope of free maintenance. As long as it is our products, we can provide technical support services.


Q: What is the minimum order quantity?
A: The minimum order quantity depends on the product size.

Q:Products are in stock? How long can you deliver?
A:Our inventory is mainly semi finished products and raw materials and a small amount of finished goods. Small batch delivery needs 2-3 week, mass delivery takes 3-4 weeks.


Product Show
