Electronics Spare Parts STN HTN FSTN Graphics LCD Screen Module

Electronics Spare Parts STN HTN FSTN Graphics LCD Screen Module

  • High Light

    800RGB×480 Lcd Segment Display

    ,

    HX8664 IC Lcd Segment Display

    ,

    Graphics Controller Tft Lcd Display Module

  • Product Name
    Electronics Spare Parts STN HTN FSTN Graphics LCD Screen Module
  • Screen Code
    Segment And Dot Matrix
  • BG Color
    Yellow/blue/white
  • Certs
    CE ROHS
  • Original
    Shenzhen, China
  • Customize
    Support
  • MOQ
    1 PC
  • Lead Time
    7-15days
  • Warranty
    12months
  • Dimension
    Customize
  • Place of Origin
    China
  • Brand Name
    QIHANG
  • Certification
    CE ROHS
  • Model Number
    JXL-19264-1D
  • Minimum Order Quantity
    100
  • Price
    0.1
  • Packaging Details
    blister packing within carton
  • Delivery Time
    7-15DAYS
  • Payment Terms
    L/C, T/T, Western Union, MoneyGram
  • Supply Ability
    100,000piece/ month

Electronics Spare Parts STN HTN FSTN Graphics LCD Screen Module

Electronics Spare Parts STN HTN FSTN Graphics LCD Screen Module



Digital displays improve the user interface of just about any application. Segmented LCDs have historically been a popular choice of display technology and their use continues to grow in a variety of medical and industrial applications. In recent years there has been a significant rise in the use of graphical displays—such as TFT, OLED and CSTN—in consumer, appliance and automotive applications. Users prefer intuitive menus, vivid graphics, touch panel interaction and, in some cases, the ability to interact remotely with a system.



Name Electronics Spare Parts STN HTN FSTN Graphics LCD Screen Module
Product size Customize
Boundary dimension 120.7MM*75.8MM*2.8MM
Display (A, areaA) dimensions 108MM x 64.8MM
resolving power 800RGB×480
View direction TN
Connection mode FPC Plug in
Interface RGB-40PIN
Drive IC HX8264-D05/HX8664
Drive voltage 3.3V
LED current voltage 19.2V/40MA
Brightness: CD / m2 430
Working temperature -20°~70°
Storage temperature -30°~80°





5 Inch Graphics Controller Segment Tft Cheapest Lcd Display Module



Application Cases:



Electronics Spare Parts STN HTN FSTN Graphics LCD Screen Module 0

Electronics Spare Parts STN HTN FSTN Graphics LCD Screen Module 1



5 Inch Graphics Controller Segment Tft Cheapest Lcd Display Module



Producing Procedures:



Electronics Spare Parts STN HTN FSTN Graphics LCD Screen Module 2

Electronics Spare Parts STN HTN FSTN Graphics LCD Screen Module 3



5 Inch Graphics Controller Segment Tft Cheapest Lcd Display Module



Qihang Workshop:



Electronics Spare Parts STN HTN FSTN Graphics LCD Screen Module 4

Electronics Spare Parts STN HTN FSTN Graphics LCD Screen Module 5



F A Q:



Q1:How long is the warranty?

A:The warranty period is one year.During the warranty period, in case of non-human injury, we will provide free repair or replacement, including delivery costs.Beyond warranty: we provide repair parts at a lower cost and provide services free of charge.

Q2:Do you accept customization?

A:Yes, we are glad to provide customized services.Our factory can design and produce the appearance, logo, material, color, size,installation method and so on according to customers' requirements.

Q3:What are your payment terms?

A:Sample 100% TT,batch order 30% deposit, 70% balance before delivery

Q4:How long is the delivery time?

A:For the finished products in stock, the delivery time is within 3-7 days;No inventory for 20-25 days;For customized samples and bulk orders, the lead time is 7-30 days.

Q5:How can I get a sample?

A:Since most of our products are high value products, there are no free samples.If you need to order a sample for inspection, we would like you to pay the sample fee and freight, and the sample will be sent to you upon receipt of payment.
