Home > products > OLED Display Module > Customize OEL1M4213 W E Parallel 4 SPI IIC 2.42" OLED Display Module

Customize OEL1M4213 W E Parallel 4 SPI IIC 2.42" OLED Display Module

Product Details

Place of Origin: Shenzhen, China

Brand Name: Qihang

Certification: ROHS/CE

Model Number: JXL-2.42" OEL1M4213-W-E

Payment & Shipping Terms

Minimum Order Quantity: 1 pcs

Price: Negotiable

Packaging Details: Tray , Standard carton

Delivery Time: 10-15 Days

Payment Terms: T/T, L/C, D/A, D/P, Western Union, MoneyGram, paypal

Supply Ability: 300000 Per Month

Get Best Price
Highlight:

SSD1309ZC OLED Display Module

,

2.42" OLED Display Module

,

128x64Dots OLED Display Module

Resolution:
128x64 Dots
Diagonal Size:
2.42" Oled Module
Active Area (mm):
55.01 Mm X 27.49 Mm
Panel Outline Dimension (mm):
60.5 Mm X 37.00 Mm
Drive IC:
SSD1309ZC
Thickness:
1.25 Mm
Pixel Pitch:
0.43 Mm X 0.43 Mm
Pixel Side:
0.40 Mm X 0.40 Mm
Name:
OEL1M4213 W E Parallel 4 SPI IIC 2.42" OLED Display Module
Warranty:
12months
Resolution:
128x64 Dots
Diagonal Size:
2.42" Oled Module
Active Area (mm):
55.01 Mm X 27.49 Mm
Panel Outline Dimension (mm):
60.5 Mm X 37.00 Mm
Drive IC:
SSD1309ZC
Thickness:
1.25 Mm
Pixel Pitch:
0.43 Mm X 0.43 Mm
Pixel Side:
0.40 Mm X 0.40 Mm
Name:
OEL1M4213 W E Parallel 4 SPI IIC 2.42" OLED Display Module
Warranty:
12months
Customize OEL1M4213 W E Parallel 4 SPI IIC 2.42" OLED Display Module

OEL1M4213 W E Parallel 4 SPI IIC 2.42" OLED Display Module



Quick Details



Name OEL1M4213 W E Parallel 4 SPI IIC 2.42" OLED Display Module
Items Specification Unit
Diagonal Size
2.42
Inch
Resolution
128(H) x 64(V)
Dots
Active Area
55.01(W) x 27.49(H)
mm 2
Outline Dimension
60.5(W) x 37.00(H)
mm 2
Pixel Pitch
0.43(W) x 0.43(H)
mm 2
Pixel Size
0.40(W) x 0.40(H)
mm 2
Driver IC
SSD1309ZC
-
Display Color White -
Gray Scale 1 Bit
Interface
Parallel / 4-SPI / IIC

IC Package Type
COG with Flex for ZIF
-
Module Connecting Type
ZIF
-
Thickness
2.0±0.2
mm
Weight TBD g
Duty 1/64 -



Quality Control



Qihang always adheres to the "quality first" concept, strictly controls the various processes of production operations, and conducts 100% inspection of shipped products.



Packing & Delivery



Shipping Terms DHL / TNT / FEDEX / UPS / EMS / Other
Packing Carton Box
Payment Terms Paypal / T/T
Color Transparent
Delivery time 1 - 3 working days
MOQ 1 pcs
Quality OEM NEW
Type 2.42 inch OLED
Product Keywords OLED LCD Display Module





Technical Service



If you have technical problem with the product you received from us, please contact us online or by email
Remote help service: If your problem needs to be solved by remote help by our engineer, please download the teamviewer software, install it on your computer, then give us ID and password for remote help.



Sample Policy



Contact us for information regarding our sample policy



FAQ



Q: What about the delivery time?
A: The LCD products need 3-6 weeks to be made after receive deposit.

Q: Does your product have any warranty?
A: Yes, we offer 12 months warranty for our products. Damage due to misuse, ill treatment and unauthorized modifications and repairs are not covered by our warranty.

Q: What's your payment method?
A: We usually accept the payment methods include T/T, D/P, Western Union and Paypal. 30% deposit in advance and balance before shipping upon the payment amount.



Q: What is the MOQ?
A: Generally if you choose the different products, our minimum order qty also will be different.


Q: What's your shipping method?
A: We provide comprehensive shipping methods.Display
For small quantity orders we ship by UPS Air-Express,or DHL/FEDEX/TNT/EMS Express service, it is safe and fast.
For large quantity orders we ship by buyer's cargo agent in China, we can also ship by Air transportation or sea transportation.

Q: Do you offer custom solution?

A: Yes,we can offer custom solution if standard products couldn't meet buyer' requirements.



Product drawing



Customize OEL1M4213 W E Parallel 4 SPI  IIC 2.42" OLED Display Module 0
