Name: |
White LED Backlight 192 64 Dot Matrix LCD Display Module |
Display Type:: |
192*64 |
Front Polarizer: |
Transmissive Polarizer |
Back Polarizer: |
Reflective Polarizer |
Operating Temp: |
-20℃~+70℃ |
Storage Temp: |
-30℃~+80℃ |
LCD Operating Voltage: |
3V ~ 5.0V |
View Direction: |
6 O'clock / 12 O'clock |
Connection: |
PIN |
Driver IC: |
S6A0107 Or AIP31107 Or Equal |
Name: |
White LED Backlight 192 64 Dot Matrix LCD Display Module |
Display Type:: |
192*64 |
Front Polarizer: |
Transmissive Polarizer |
Back Polarizer: |
Reflective Polarizer |
Operating Temp: |
-20℃~+70℃ |
Storage Temp: |
-30℃~+80℃ |
LCD Operating Voltage: |
3V ~ 5.0V |
View Direction: |
6 O'clock / 12 O'clock |
Connection: |
PIN |
Driver IC: |
S6A0107 Or AIP31107 Or Equal |
White LED Backlight 192 64 Dot Matrix LCD Display Module
19264 dots matrix LCD module feature
| Name | White LED Backlight 192 64 Dot Matrix LCD Display Module |
|
item |
value |
|
Module NO |
JXL-19264B-1 |
|
COB Type |
192*64 Dots |
|
Module Size |
100.0(L)*60.0(W)*12.0(H) (mm) |
|
Viewing Area |
83.9*30.8 (mm) |
|
Active Area |
78.67*26.19 (mm) |
|
Dot Size |
0.36*0.36 (mm) |
|
Dots pitch |
0.05 (mm) |
|
Operate Voltage |
5.0V |
|
Viewing Direction |
6:00 |
|
Interface |
6800/8080 8-Bit Parallel / 20P / 2.54MM |
|
Controller IC |
S6A0107 or AIP31107 or Equal |
|
Backlight Current(Typ) |
90 mA |
|
Operating Temperature |
-20℃ ~ +70 ℃ |
|
Storage Temperature |
-30℃ ~ +80 ℃ |
LCD Module can display letters, numbers, Chinese fonts and graphics, mixed with graphics and text display screen. Can display 192 (columns) × 64 (rows) lattice. Complete graphical display can also display 12×4 pcs (16 × 16 dot matrix) Chinese characters.
19264 lcd module Quick Details
Model Number: JXL-19264B-1
Brand Name: Qihang
Type: STN
Backlight: White LED Backlight
Polarizer Type: Transmissive / Negative
Interface: MCU-8 Bit / MCU-16 Bit
Driving Method: 1/64 Duty, 1/9 Bias
Viewing Direction: 6 O'clock / 12 O'clock
Operating Voltage: VOD=5.0 V
Operating Temp: -20℃ to +70℃
Storage Temp: -30℃ to +80℃
Place of Origin: Shenzhen, Guangdong, China
Certification: ROHS, CE
Providing Excellent Service
We are not only manufacture products,but also provide display solution.We can realize your project from your product concept to real product,to help you save sourcing cost.In the mean time.we provide competitive price,on-time delivery and efficeint work with customers.
Qihang company owns successful experience of 150+ big projects,
Qihang LCM provides instant delivery for standard products from stock,
7-15 days for new samples, 7-10 days for new FPC,
15 days for new Backlight,18 days for new Capactive touch panels,
Lead time for mass production of standard products could be as fast as 15 days,
Lead time for special products is as fast as 3 weeks.
Application
Our products are used in a wide range of applications, such as electronic equipment, medical equipment, industrial equipment and smart home.
Providing Good products:
All products are 100% tesed before shipment .We will do reliability tests,including high & low terperature tests,heat impact test and vibration test as per customer's special requirements.
Packaging
Choose the right package according to the size of the product and carry out multiple protections to ensure that the product avoids damage during transportation.
FAQ
1.Long Term Continuity Supply Warranty.
We understand you probably worry whether we still offer the display after your long development time. Qihang gives the promise to
every customer to every product we sell on this web store. We promise the long terms continuity supply and would never end
supply.Some controller IC may stop the production,we’ll try our efforts to find the completely compatible ones.If the equivalent
is unavailable, we’ll make the new tooling and use the most similar IC as replacement.So you don't have to worry even your
research time is very long.
